| W x D x H |
48" x 311/2" x 40"
|
| Weight |
390 lb
|
| Power Input Type | Electric |
| Primary Power Input | 115-120 V x 60 Hz x 1 PH |
| Energy Use | 2.9 Amps |
| Certifications |
    |
18600BSTMP
Self-Contained Refrigerated Work Tables With Backsplash
|
Exterior Top
Exterior top is constructed of heavy duty stainless steel, with integral 2.12" (5cm) high square nosing at the front. Top is insulated with high-density insulation. Exterior back and bottom are galvanized steel. Exterior ends are finished with stainless steel. |
|
Interior
Interior base has stainless steel back and bottom. Interior ends and door frames are thermoformed ABS plastic. Base is insulated with high-density foamed-in place environmentally friendly, Kyoto Protocol Compliant, Non ODP (Ozone Depletion Potential), Non GWP (Global Warming Potential) polyurethane. Each interior door section has (1) removable epoxy-coated wire shelf. |
|
Door(s)
Door(s) have stainless steel exterior front, with a thermoformed ABS plastic interior liner. Black recessed handle(s) and a snap-in magnetic gasket which is readily replaceable. |
|
Base
Base has a machine compartment, standard on right, with a condensing unit with condensate evaporator and an electrical junction box installed. Machine compartment has a removable louver for access to condensing unit. Blower coil(s) with expansion valve are located behind the door mullions. |
|
Electrical Connections
Electrical connections are 115 volts, 60 Hertz, single phase. Unit has a 8' (2.4m) long cord and plug. |
|
Casters
Casters: Unit is mounted on 5" (13cm) diameter casters; overall height of casters is 6.13" (16cm). |
|
Refrigeration System
Refrigeration system uses R290 refrigerant, and will maintain 36°F (2°C) to 40°F (4°C) interior cabinet temperature. |
18648BSTMP
18660BSTMP
| W x D x H |
60" x 311/2" x 40"
|
| Weight |
435 lb
|
| Power Input Type | Electric |
| Primary Power Input | 115-120 V x 60 Hz x 1 PH |
| Energy Use | 2.9 Amps |
| Certifications |
|
18672BSTMP
| W x D x H |
72" x 311/2" x 40"
|
| Weight |
495 lb
|
| Power Input Type | Electric |
| Primary Power Input | 115-120 V x 60 Hz x 1 PH |
| Energy Use | 4.8 Amps |
| Certifications |
 |
18691BSTMP
| W x D x H |
91" x 311/2" x 40"
|
| Weight |
535 lb
|
| Power Input Type | Electric |
| Primary Power Input | 115-120 V x 60 Hz x 1 PH |
| Energy Use | 4.8 Amps |
| Certifications |
|
18699BSTMP
| W x D x H |
99" x 311/2" x 40"
|
| Weight |
594 lb
|
| Power Input Type | Electric |
| Primary Power Input | 115-120 V x 60 Hz x 1 PH |
| Energy Use | 4.8 Amps |
| Certifications |
|
186114BSTMP
| W x D x H |
114" x 311/2" x 40"
|
| Weight |
685 lb
|
| Power Input Type | Electric |
| Primary Power Input | 115-120 V x 60 Hz x 1 PH |
| Energy Use | 6.3 Amps |
| Certifications |
|
18" deep single tier stainless steel overshelf |
|
Additional shelf (specify door size) |
|
Cutting board (1/2" thick x 20" wide) |
|
Laminate back |
|
Laminate end |
|
Laminate facing (full front) |
|
Legs, set of four or six |
|
Locks |
|
Refrigerated drawers, (2 or 3 high) 19", 24", 27" or 32" wide |
|
Tray Racks |
|
Celsius readout for electronic control |
