All-Purpose Section – A 24" wide high-heat all-purpose hot top with thermostatic control, 290°F (143°C) to 650°F (343°C), for cooking flexibility. A 5kW heater for every 12” width of 3/4” steel plate.
Elements – Two powerful 2.1 kW, 8in (203mm) dia. tubular heating elements with 3-heat switch control ensure consistent output and temperature regulation, even under heavy volume use. Rugged controls and circuit-breakers/fuses outside heat zones for electric circuit protection, safety, and service access.
Front and rear grease troughs to catch excess grease and spillage that drains into grease pans under the range top.
| W x D x H |
36" x 36" x 36"
|
| Weight |
575 lb
|
| Power Output | 20.7 Kilowatts |
| Power Input Type | Electric |
| Primary Power Input |
208-240 V x 60 Hz x 1 PH 208-240 V x 60 Hz x 3 PH |
| Certifications |
![]() ![]() |
